Newsletter Vol.46

Workpiece: Electric vehicle shaft

Model: JHU-3506CNC Cylindrical and JHI-150CNC Internal Grinding

JHU-3506CNC capacity: Max. OD Ø330mm, grinding length 300mm

JHI-150CNC capacity: ID Ø6-150mm, max. holding length: 200mm

Automation: Equipped with automatic device to increase production efficiency (Send your inquiry and workpiece drawing)

Applications:
electric vehicle (EV) parts, aerospace and other transportation industry, electronic industry , machine tool precision parts ,gear motor parts, pumps industry, energy industry, precision hardware, recreation industry.

Centerless – Tungsten Carbide Rod Infeed Grinding Solution

The feature of tungsten carbide is high hardness and wear resistance. It's high conductivity of heat leads to high temperatures and vibration issues during the grinding process that making grinding operations full of challenging.

In this case, we use JHC-2416T-CNC7 centerless equipped with an automated gantry loading / unloading device provides customers with an efficient, precise, and sustainable solution for grinding tungsten carbide rods.

The JHC-2416T-CNC7 centerless machine is equipped with a 405mm width grinding wheel which is capable of heavy grinding. The CNC program controls feeding, dressing, and compensation. There’s no need to adjust the loading / unloading device when the grinding & regulating wheels wearing.

The tungsten carbide rod is held and proceeds reciprocating grinding by the gantry device. This approach not only avoids radial and axial run-out, keep grinding stability, but also improves grinding efficiency, reduces production costs and minimizes operational risks.

Send your inquiry and drawing to us!

/ Exhibition /
2023 EMO Hannover

/ Date of exhibition /
2023. Sep.18 - 23,2023 (Mon. - Sat.)

/ Location /
SECC, HCMC , Vietnam

/ Booth /
Hall A2 | AK5-1

/ Exhibition /
MTA Vietnam 2023

/ Date of exhibition /
2023.Jul.4 (Tue.) to Jul.7 (Fri.)

/ Location /
Hannover Exhibition Grounds, Germany

/ Booth /
Hall 11 | C56

Our office will be closed in June 22 to 25 due to the Dragon Boat Festival in Taiwan. Please leave your message and we’ll respond to your at once when return. Thank you for your understanding & continuous support !
